BLOW MOLDING MACHINES
PE-1L BLOW MOLDING MACHINE
Volume
0.15 - 1 L
Material
PE/PP
Screw D/ Productivity
55 mm / 25 Kg/hr
Capacity
270 BPH (max)
Clamping Force
4.3 T
Product Size (mm)
Mold Size (mm)
H220×W100×T90
H280×W180×T170
Power
30 Kw
Configuration
Auto Loading & Feeding System, Single Station, Single Head, Single Layer
PE-2L BLOW MOLDING MACHINE
Volume
2 L (max)
Material
PE/PP
Screw D/ Productivity
45 mm / 35 Kg/hr
Vice Screw D
20 mm
Clamping Force
2.5 T
Mold Opening (mm)
Mold Size (mm)
140mm
H320×W250×T180
Power
20 Kw
Configuration
Auto Loading & Feeding System, Double Station, Double Head, Single Layer (with Vice Line)
PE-5L BLOW MOLDING MACHINE
Volume
5 L (max)
Material
PE/PP
Screw D/ Productivity
65 mm / 70 Kg/hr
Vice Screw D
Non
Clamping Force
6 T
Mold Opening
Mold Size (mm)
240 mm
H430×W320×T260
Power
35 Kw
Configuration
Auto Loading & Feeding System, Single Station, Single Head, Single Layer
PC-5L BLOW MOLDING MACHINE
Volume
5 L (max)
Material
PC
Screw D/ Productivity
80 mm / 160 Kg/hr
Capacity
55 BPH
Clamping Force
10 T
Platen Distance
Platen Dimension
350 - 780 mm
550 x 650 mm
Power
40 Kw
Configuration
Auto Loading & Feeding System, Single Station, Single Head, Single Layer
PE-15L BLOW MOLDING MACHINE
Volume
5 - 15 L
Material
PE/ PP
Screw D/ Productivity
75 mm / 70 Kg/hr
Capacity
150 BPH
Clamping Force
12 T
Product Size (mm)
Platen Dimension
H570×W270×T250
H800×W380×T400
Power
42 Kw
Configuration
Auto Loading & Feeding System, Single Station, Single Head, Single Layer, Parison Controller
PE-20L BLOW MOLDING MACHINE
Volume
20 L (max)
Material
PE/PP
Screw D/ Productivity
90 mm / 120 Kg/hr
Vice Screw D
20 mm
Clamping Force
19.6 T
Mold Stroke
Mold Size (mm)
350 - 700 mm
H700×W650×T440
Power
133 Kw
Configuration
Auto Loading & Feeding System, Double Station, Single Head, Single Layer with Vice Line, Parison Controller
PET-2000 AUTOMATIC PREFORM BLOW MOLDING MACHINE
Cavity
4
Material
PET
Bottle Volume
2000 mL (max)
Capacity
8000 - 10000 BPH
Bottle Height
328 mm (max)
Bottle Height
100 mm (max)
Heating Oven Power
26 Kw
Power
55 Kw
Configuration
Two Stages , Clamping Force: 36 Ton, Preform: Neck Size (mm): L 15 - 25, H 150
PET-1500 AUTOMATIC PREFORM BLOW MOLDING MACHINE
Cavity
4
Material
PET
Bottle Volume
100 - 1500 mL
Capacity
2400 BPH
Bottle Height
350 mm (max)
Mold Size (mm)
H400×W510×T165
Heating Box No
28
Power
50 Kw
Configuration
Two Stages , Clamping Force: 25 Ton, Preform: Neck Size (mm): 30, L 15 - 25, H 70 - 170
PET-600 AUTOMATIC PREFORM BLOW MOLDING MACHINE
Cavity
4
Material
PET
Bottle Volume
50 - 600 mL
Capacity
2600 BPH
Bottle Height
210 mm (max)
Mold Size (mm)
H250×W450×T135
Heating Box No
28
Power
40 Kw
Configuration
Two Stages , Clamping Force: 16 Ton, Preform: Neck Size (mm): 30, L 15 - 25, H 70 - 170
PE-2000 AUTOMATIC INJECTION BLOW MOLDING MACHINE
Cavity
8 - 18
Material
PE/PP/PC
Bottle Volume
2 - 2000 mL
Bottle Weight
35 gm (max)
Inj. Clamp Force
100 T
Blow Clamp Force
13 T
Screw D/Shot W/Rate
60 mm/390 gm/ 80 Kg/hr
Power
60 Kw
Configuration
One Step, Type: Vertical , Bottle D: 70 mm (max), Neck Size (mm): Neck D: 46 mm, H: 185 mm (max)
